MORI-SAY 620AC

MORI-SAY 620AC
Traditional cam automatic lathe of the high accuracy, rigidity and quickness. It is intended for the mass and series production of precise components from the bar stock.
Request

Traditional cam automatic lathe MORI-SAY 620 AC

Mori-Say 620 AC – Traditional cam automatic lathe of the high accuracy, rigidity and quickness. It is intended for the mass and series production of precise components from the bar stock.
The characteristics of concept is a high precision and inflexibility with machining on six spindles with six independent longitudinal saddles, six cross saddles and four cross saddles. The machine enables the usage of various types of automatic feeders and automatic feeders of material.

  • No. of spindles: 6
  • Max. diameter of bar:20 mm
  • Max. length of feeding: 100 mm
  • Spindle speed: max 6000 rpm

STANDARD EQUIPMENT

  • Spindle drum locking by a triad of rims with spur gearing
  • SIMODRIVE SIEMENS variable speed motors
  • PLC – SIEMENS SIMATIC programmable logic controller, S 7.300 model
  • 6 cross slides and 6 frontal slides
  • 4 compound slides in the 1st, 2nd, 4th and 5th stations
  • Standard bar stock guide
  • Feeding, clamping and bar stop in the 6th station
  • 4 safety clutches preventing from the slides overloading
  • Independent drive of the central block

MACHINE VERSIONS

  • MORI-SAY 620AC
  • MORI-SAY 620SAC – machines with stop of spindles

OPTIONAL EQUIPMENT

  • Feeding, clamping and bar stop in the 3rd station
  • Device for the general stop of spindles – 620SAC version
  • Hydraulic oriented stop of spindles – 620SAC version
  • NC oriented stop of spindles – 620SAC version
  • Pick-up spindle with hydrauliccally controlled collet clamping
  • Brake of the pick-up spindle
  • Pick-up tool slide with a mechanical drive
  • Tool holders
  • Tapping and thread chasing attachments
  • Thread rolling with two roller dies
  • Attachment for outer polygon machining and thread milling
  • Attachment for internal polygon machining
  • Cams for frontal, cross and compound slides
  • Necking-down attachment
  • High-speed drilling attachment
  • Rotary reaming attachment
  • NC compound slides for the 4th and 5th stations
  • Preparation for the automatic bar magazine
  • Preparation for the oil mist exhaustion
  • Selection of the equipment for swarfs carrying out and coolant in an independent sedimentation tank
  • High-pressure coolant and tool wash-out
  • Setting-up for a part machining and the machine acceptance in the TAJMAC-ZPS plant
